DESCRIPTION
The MRCOOL ProDirect 4 Ton 14 SEER Multiposition Split System Air Handler is the answer to every single heating and cooling issue youve had. You wont have to struggle with rising bills or inconsistent temperatures once this units “A" shaped evaporator coil gets to work in your home. The three-speed direct drive blower motor ensures that every square inch of your home is covered in exactly the temperature you want. The removable filter purifies air before you ever breathe it so youre only surrounded by the cleanest and freshest air. You can even have an electric heat kit installed in this air handler for extra heating power. This air handler is protected by a corrosion resistant galvanized steel cabinet that helps your home stay comfortable by keeping your unit safe. Youll be pleased to learn that this unit is AHRI certified and ETL listed, so you know that this air handler is high quality. When you register this product online, youll enjoy long warranty protection to keep you calm if anything goes wrong. Never wrestle with your thermostat or feel despair over bills once you install this MRCOOL ProDirect 4 ton split system air handler.
FeaturesEquipment should be installed by a qualified professional10 Year Registered WarrantyAHRI Certified & ETL listed
SPECIFICATIONS
Dimensions |
53-1/8"H x 22"W x 24"D |
Weight |
176 lbs |
SEER |
14 |
CFM |
1695/1574/1434 |
Cooling Capacity |
48000 BTU |
Voltage |
208-230 V |
Phase |
1 |
Cycle |
60 Hz |
Decibal Rating |
51-54 dBA |
Decibal Rating Low |
51 dBA |
Decibal Rating High |
54 dBA |
Number of Speeds |
3 Speed |
Blower Motor Speeds |
3 Speed |
Blower Motor RPM |
920/870/820 |
Filter Type |
Replacable |
ETL Listed |
Yes |
AHRI Certified |
Yes |
Registered Warranty |
10 Year Limited Warranty |
Gross Depth |
25-1/5in |
Gross Height |
54-3/4in |
Gross Width |
28in |
Gross Weight |
190 lbs |
PRODUCT DOCUMENTATION
BrochureInstall ManualSpecsWarranty Doc
